Driving Type

LHD (RHD is optional)

Cabin

HW76,(one sleeping, with air-condition)

Engine

Engine model: WP10., Euro 2, 340 HP ,380HP ,400HP ,430HP,Displacement: 10 L

Transmission

HW19710, 10F & 2R, with PTO

Steering

ZF power steering, model ZF8118, hydraulic steering with power assistance

Front Axle

VGD95,1×9500 KGS

Rear Axle

HC16, 2×16000 KGS

Ratio:5.73

Chassis

Front suspension:10 semi elliptic leaf spring, hydraulic telescopic double-action shock absorbers and stabilizer

Brake

Service brake: dual circuit compressed air brake

Parking brake (emergency brake): spring energy, compressed air operating on front shaft and rear wheels

Auxiliary brake: engine exhaust brake

Electrics

Starter: 24 V, 5.4 Kw

Alternator: 3-phase, 28 V, 1500 W

Batteries: 2 × 12 V, 165 Ah

headlamps, fog lights, brake lights, indicators and reverse light

Tyres

12.00R20, radial tyres with one spare tyre

Fuel Tank

300L

Cargo Body

5400*2300*1500 mm, 18 CBM, Floor 8mm Side 6mm

Overall Dimension

8250*2550*3450mm
